Lithium Solar Batteries 12v 120ah Deep Cycle Battery

Product Parameters

That guarantee us to supply most competitive cells , battery pack and BMS solutions with advanced lithium technology .

12V 120Ah LiFePO4 batteryBasic characteristics
Weight		14.6kg
Size		406178236mm orcustom
Working Temperature	Charge	-20°C~ 45°C , 65±20%RH;
Working Temperature	Discharge	-20°C ~65°C , 65±20%RH
Storage Temperature	Less than 1 month	-20°C~ 45°C
Storage Temperature	less than 3 months	-20°C~ 35°C
Retention of charge(store in one month)		above 95%
2. Technical Data
Rated Voltage		12.8V
Rated Capacity		120Ah
Inner Resistance		below 50 mΩ
Charge & Discharge	Way of charge	CC/CV(Constant Current / Constant Voltage)
	Standard Charge Current	20A~50A (Adjustable)
	Max Charge Current	100A
	Over Charge cut-off voltage	14.6v±0.025V(optional)
	Continuous Discharge Current	≤ 40A or custom
	Dischargecut-off voltage	10v ±0.025V(optional)
	Peak Discharge Current	70A or custom per requirement
	Cell Over Charge Protection Voltage	3.65v ±0.025V(optional)
	Cell Over discharge Protection Voltage	2.5v ±0.025V(optional)

Product Description

Vglory battery manufacturer provide high quality lithium battery assembled with high quality A grade cell . which is good replacement for lead-acid battery , we can custom any lithium battery mainly : Solar energy storage battery , E-vehicle battery , e-motorcycle battery , e-bike battery , Rickshaw battery , forklift battery . the charging system can be kept the same and no additional accessories are required to perform the replacement.

Widely applications such as: solar battery storage , E-vehicle , e-motorcycle , e-forklift , etc
Vglory lithium battery is more safety and reliable than the lead acid one . Compacted size and super light weight . with built-in Stable BMS system keep the best performance all the time .

这里可以自定义设置

Product Characteristics

Place of Origin	Guangdong, China
Brand Name	Vglory or OEM
Model Number	BLP12V120AH
Capacity	12v120ah
Battery type	solar power battery
Product name	best battery for solar system
Material	Li-Ion cell
Warranty	2 Year
Charge Current	0.2C
Discharge Current	0.5C
Charge Cut-off Voltage	14.6v
Discharge Cut-off Voltage	10.0v

Product Details

We have professional cell engineer and mechanical engineer who can design the ideal battery pack according our customer’s

mechanical and electric requirement balanced with suitable cost structure

这里可以自定义设置

Our Lithium Battery Features

Environment-friendly

Clean and Green energy ,Pollution-free

Compacted size and super light weight

best power-to-weight radio

Wide temperature range

Excellent widely temperature range performance

High Safety characteristic

Extremely safe and stable chemistry

High energy density

energy density are more higher than lead acid battery

Long life-cycles

Its cycle life more than 2000 cycles

Intelligent charge system

each cell can be protected and battery be charged balance

Our Strict quality testing for battery pack processing

1. Battery cells capacity sorting: Automatic cell grading sorting ensure the precision of cell balance as ensure the best capacity and quality of battery pack ;
2. Battery cells IR testing: Taking cell internal resistance testing which keep the battery in best consistency as ensure the best battery pack combination , which ensure the best power performance and cycle life of good quality battery pack .
3. Automatic Welding machine: Automatic welding which can avoid insufficient welding as ensure the high quality battery pack. and improve production efficiency mostly .
4. Aging test: Using automatic test equipment , comprehensive test of large batteries , charge-discharge cycles , accurate data , perfect curve , ensure 100% qualified .
5. Automatic sticker machine: The processing of assembly the barcode of batteries can record the capacity , voltage , power, production time , and production batch of each cell for easier trace in the future .
6. Package design: Our professional engineer will design the strong package for lithium battery which ensure the safety transportation of lithium battery, which would avoid severe vibrating, impacting , extrusion, and direct light and rain.
