Professional Manufacturer of One Stop Solutions Provider for all kind of lithium battery 10 years more .
Model: BP72V40Ah
MOQ: 5pcs
Payment: T/T , Western Union , Paypal
Delivery time: 10days ~ 15days
Start Port: Shenzhen
Certification: CE , ROHS , MSDS , UN38.3
Specification of lithium battery 72v 40ah | ||
No. | Items | Specs |
1 | Model | lithium battery 72v 40ah |
2 | Chemistry | Li-ion battery cell |
3 | Nominal Voltage | 72V |
4 | Rated Capacity | 40Ah |
5 | Battery Cell | 3.7v or 3.2 lithium battery cell |
6 | Battery size | 200*200*270mm /custom |
7 | Battery Weight | 31.8 kgs |
8 | Max Constant Discharge Current | ≤ 30A or custom |
9 | Standard Charge Current | ≤ 8A~10A or custom |
10 | Continuous Discharge Current | ≤ 18A or custom |
11 | Rated charged Voltage | 74V (3.7V per cell) |
12 | Overcharge cut off voltage | 84V( 4.2V per cell) |
13 | Discharge cut off voltage | 60v |
14 | Way of Charge | CC/CV(Constant Current / Constant Voltage) |
15 | Cycle Life | >2000 times (80% of initial capacity at 0.2C rate) |
16 | Charge Temperature | 0~45°C 60±25%R.H. |
17 | Discharge Temperature | -20~55°C 60±25%R.H. |
18 | Storage temperature | -0~35°C 45-75% R.H. |
21 | Protection Function | Over-Current Protection,Over-Discharge Protection, Over-Charge Protection,Short-Circuit Protection, Teperature, Balance |
Product Description
Vglory battery factory producing high quality lithium battery by assembled with high quality A grade battery cell. which are good replacement of lead-acid batteries and good compatible. the charging system no need change and no need any additional accessories.
lithium-ion batteries are now more popular in defense applications, automotive, and aerospace applications due to their high energy density. Li-ion batteries are lighter than other equivalent secondary batteries
Lithium batteries are common widely use in many fields . which is most popular type of battery. with best capacity-to-weight ratios, no memory effect, and a lot of advantages for using the lithium battery.
Product Characteristics
Place of Origin | Guangdong, China |
Brand Name | Vglory or OEM |
Model Number | BP72V40AH |
Capacity | 72v40ah |
Battery type | E-motorcycle, e-tricycle/rickshaw, e-golf cart, |
Material | Li-ion battery cell |
Warranty | 2 Year |
Charge Current | 0.2C |
Discharge Current | 0.5C |
Charge Cut-off Voltage | 84v |
Discharge Cut-off Voltage | 60v |
Environment-friendly
lean and Green energy poses no pollution on our environment . Extremely safe and stable chemistry
Customized
Capacity ,voltage and size could be customized , can assembled battery cell in parallel or series into stacks as requested !
Wide temperature range
Excellent widely temperature range performance from :-20°C~+60°C.
Wide range power capacity available
12v 24v 36v 48v 60v 72v 5ah~300ah
Long circle cycles
Rechargeable be circularly used , more than 2000 charge /discharge cycle , 8times of Lead-acid battery.
Low internal resistance
Which ensure the best performance of lithium battery pack .
Maintenance Free
Just charge it once every month if you are not using it
Excellent power performance
Best consistency & High Stability power performance, Super high discharge rate etc
Low internal resistance
low self-discharge rate
No memory effect
Always ready for charge and discharge , no need to charge after a full discharge
PCM & BMS Protection
Protection - Dual IC chips, anti-short circuit, anti-over charger, anti-over current, anti-overload etc.
