Professional Manufacturer of One Stop Solutions Provider for all kind of lithium battery 10 years more .
Model: BLP48V60Ah
MOQ: 5pcs
Payment: T/T , Western Union , Paypal ,
Delivery time: 10days ~ 15days
Start Port: Shenzhen
Certification: CE , ROHS , MSDS , UN38.3
Specification of 48v 60ah lithium ion battery pack | ||
No. | Model | High Capacity Density 48v 60ah lithium ion battery pack Rechargeable |
1 | Chemistry | Li-ion battery cell |
2 | Nominal Voltage | 48V |
3 | Rated Capacity | 60Ah |
4 | Battery Cell | li-ion battery cell |
5 | Battery size | 320*260*150mm or custom |
6 | Battery Weight | 29.8kgs |
7 | Max Constant Discharge Current | ≤ 30A or custom |
8 | Standard Charge Current | ≤ 10A~15A or custom |
9 | Continuous Discharge Current | ≤ 20A or custom |
10 | Fully charged Voltage | 48.1V (3.7V per cell) |
11 | Overcharge cut off voltage | 54.6V( 4.2V per cell) |
12 | Discharge cut off voltage | 39 (3V per cell) |
13 | Standard Discharge | Constant Current 0.2C/End Voltage 39V |
14 | Way of Charge | CC/CV |
15 | Cycle Life | >1500 times (80% of initial capacity at 0.2C rate) |
16 | Charge Temperature | 0~45℃ 60±25%R.H. |
17 | Discharge Temperature | -20~55°C 60±25%R.H. |
18 | Storage temperature | -0~35°C 45-75% R.H. |
21 | Protection Function | Over-Current Protection,Over-Discharge Protection, Over-Charge Protection,Short-Circuit Protection, Teperature, Balance |
Product Description
Vglory battery factory producing high level safety battery by assembled with high quality A grade battery cell . which are good replacement of lead-acid batteries and good compatible in all respects with those of lead battery . we can keep the charging system and not require any additional accessories for the replacement.
lithium-ion batteries are growing in popularity for solar energy storage, e-mobility, automotive, telecom/base station, uninterruptible power supply/UPS/backup system, aerospace applications due to their high energy density. Li-ion batteries are lighter than other equivalent secondary batteries-often much lighter. The energy is stored in these batteries through the movement of lithium ions.
It is more safety and reliable than the lead acid battery . which is more compacted size and super light weight.
Product Characteristics
Place of Origin | Guangdong, China |
Brand Name | Vglory or OEM |
Model Number | BLP48V50AH |
Capacity | 48v6ah |
Battery application | Battery for e-scooter, e-skateboard, e-motorcycle, e-tricycle/rickshaw,e-golf cart, |
Material | Lifepo4 cell |
Warranty | 2 Year |
Charge Current | 0.2C |
Discharge Current | 0.5C |
Charge Cut-off Voltage | 54.6v |
Discharge Cut-off Voltage | 39.6v |
No memory effect
ready be charged & discharged at anytime , economically and conveniently to be use any time
High energy density
energy density per volume are higher ;
Long cycle life
over 2000 cycle 8 times circle life of Lead Acid
Environment-friendly
Clean and Green energy as no pollution on our environment . not contain any hazardous and noxious substances
Deep cycle rechargeable to be used regularly
Lower average price per year
the average price per year is more economic than the lead-acid battery
Custom Acceptable
capacity , voltage , shape , size , case etc
Low self-discharge
Minimal self-discharge, only less than 3% monthly.
Compacted size and super light weight
Light weight , small size and high power performance ,only 1/3 weight of lead acid battery
Excellent power performance
Capacity, resistance, Voltage, platform time consistency is good
High Safety characteristic
Extremely safety and stable chemistry : no explosion, no fire under collision etc
Our Strict quality testing for battery pack processing
Battery cells capacity sorting: Automatic cell grading sorting ensure the precision of cell balance as ensure the best capacity and quality of battery pack
Battery cells IR & multi testing: Undertaking internal resistance testing ensure the best consistency of best quality battery pack, as ensure best power performance and prolong lifespan of battery pack.
Automatic Welding machine: which can avoid insufficient welding as ensure the high quality battery pack assembling. which can improve production efficiency mostly.
Aging Testing: Using automatic test equipment, tesging of large batteries, circle life, IR, consistency, accurate data, perfect curve, 100% qualified.
Automatic sticker machine: The processing of assembly the barcode of batteries can record the capacity, voltage, power, production time, and production batch for easier trace in the future.
Package design: Our skillful engineer will design the stable package for the safety during long transportation by air or sea shipments
Vglory battery factory have been in this field for many years which is established in year 2010 and have rich experiences in R&D
