Lithium battery 60v 40ah lithium battery chargers for Forklift

这里可以自定义设置
Lithium battery 60v 40ah lithium battery chargers for Forklift
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Model: BP60V40Ah

MOQ: 5pcs

Payment: T/T , Western Union , Paypal

Delivery time: 10days ~ 15days

Start Port: Shenzhen

Certification: CE , ROHS , MSDS , UN38.3


Add success, do you want to check your shopping cart?

暂无分享
该产品后台详情无内容

Product Parameters

That guarantee us to supply most competitive cells , battery pack and BMS solutions with advanced lithium technology .

Specification of 60v 40ah lithium ion battery pack

No.

Model

High Capacity Density 60v 40ah lithium ion battery pack Rechargeable

1

Chemistry

Li-ion battery cell

2

Nominal Voltage

60V

3

Rated Capacity

40Ah

4

Battery Cell

3.7V or 3.2v lithium battery cell

5

Battery size

320*260*150mm or custom

6

Battery Weight

24.6kgs

7

Max Constant Discharge Current

 ≤ 30A or custom

8

Standard Charge Current

 ≤ 5A~15A or custom

9

Continuous Discharge Current

 ≤ 25A or custom

10

Fully charged Voltage

62.9V (3.7V per cell)

11

Overcharge cut off voltage

71.4V( 4.2V per cell)

12

Discharge cut off voltage

51v

13

Standard Discharge

Constant Current 0.2C/End Voltage 51V

14

Way of Charge

CC/CV

15

Cycle Life

>1200 times (80% of initial capacity at 0.2C rate)

16

Charge Temperature

0~45°C 60±25%R.H.

17

Discharge Temperature

-20~55°C 60±25%R.H.

18

Storage temperature

-0~35°C 45-75% R.H.

19

Charging Time (Std.)

4~5hours

20

Charging Time (Max.)

2~3hours

21

Protection Function

Over-Current Protection,Over-Discharge Protection, Over-Charge Protection,Short-Circuit Protection, Teperature, Balance

Product Description

Vglory battery factory producing high quality lithium battery by processing with high quality A grade battery cell. which is nicely replacement for lead-acid batteries and good compatible in all aspects. the charging system no need change and no need additional accessories


Lithium battery With long cycle life, no pollution to environment of new energy materials ! A New hope Change in future ! it is one of the most popular type of battery. since with the best energy-to-weight ratios, no memory effect , etc.
Lithium batteries are more and more common widely use in many fields such as solar storage , UPS , Telecom, military medical , also growing in popularity for defense, automotive , and aerospace applications due to their high energy density.

这里可以自定义设置

Product Characteristics

Place of Origin

Guangdong, China

Brand Name

Vglory or OEM

Model Number

BP60V40AH

Capacity

60v40ah

Battery type

Solar power battery solar power battery , e-motorcycle, e-tricycle/rickshaw, e-golf cart

Material

Lifepo4 cell

Warranty

2 Year

Charge Current

0.2C

Discharge Current

0.5C

Charge Cut-off Voltage

71.4v

Discharge Cut-off Voltage

51v

Product Details

We have professional cell engineer and mechanical engineer who can design the ideal battery pack according our customer’s

mechanical and electric requirement balanced with suitable cost structure

这里可以自定义设置

Our Lithium Battery Features

Environment-friendly

Accredited with CE,Pollution-free, environment friendly , Non-toxic, non-contaminating

Compacted size and super light weight

The best power-to-weight radio , with good power performance, but 1/2 the volume and 1/3 the weight of the lead-acid one

Wide temperature range

Excellent characteristic , available for use when the temperature ranges from 10°C to -55°C

High energy capacity density

Energy density per volume is high

Long life-cycles

Rechargeable be circularly used up to 2000 charge /discharge cycles

Low internal resistance

which ensure the best performance of lithium battery pack Economical : the average price per year is less than the lead-acid battery.

Good power performance

Capacity, resistance, Voltage, platform time consistency is good , also strong current charge and discharge capability

No memory effect

it is ready connect for charge and discharge anytime

PCM & BMS Protection

with full production of battery all the time , anti-short circuit, anti-over charger, anti-over current, anti-overload etc

Customized accepted

We could design all battery packs per your’ requirements and provide OEM service

Deep cycle & maintenance free

just charge every month if battery keep in warehouse

Component Advantage

High quality Standard of Vglory Battery

Product Application

Widely used in fields such as: E-mobility: (e-bike , e-scooter, e-skateboard, e-tourist car , e-motorcycle,

e-tricycle /rickshaw , e-wheelchair, e-golf cart, e-forklift, e-tourist vehicle, RV/ caravan, marine,etc.),
