Lithium Battery 60v 20ah Wheelchair Batteries For E-mobility

Product Parameters

That guarantee us to supply most competitive cells , battery pack and BMS solutions with advanced lithium technology .

Specification of lithium battery 60v 20ah
No.	Items	Specs
1	Model	No Pollution Lithium Motorcycle Battery lithium battery 60v 20ah
2	Chemistry	Li-ion battery cell
3	Nominal Voltage	60V
4	Rated Capacity	20ah
5	Battery Cell	18650 2500mah 3.7v and others
6	Battery size	360220170 or custom
7	Battery Weight	10.6 kgs
8	Max Constant Discharge Current	≤ 15A or custom
9	Standard Charge Current	≤ 3A~5A or custom
10	Continuous Discharge Current	≤ 15A or custom
11	Rated charged Voltage	62.9V (3.7V per cell)
12	Overcharge cut off voltage	71.4V( 4.2V per cell)
13	Discharge cut off voltage	51v
14	Way of Charge	CC/CV(Constant Current / Constant Voltage)
15	Cycle Life	>1000 times (80% of initial capacity at 0.2C rate)
16	Charge Temperature	0~45°C 60±25%R.H.
17	Discharge Temperature	-20~55°C 60±25%R.H.
18	Storage temperature	-0~35°C 45-75% R.H.
19	Charging Time (Std.)	4~5hours
20	Charging Time (Max.)	2~3hours
21	Protection Function	Over-Current Protection,Over-Discharge Protection, Over-Charge Protection,Short-Circuit Protection, Teperature, Balance

Product Description

Vglory battery factory producing high quality lithium battery by processing with high quality A grade battery cell. which is nicely replacement for lead-acid batteries and good compatible in all aspects. the charging system no need change and no need additional accessories.

Lithium batteries are common wide use in many fields such as storage, military medical, also growing in popularity for defense, automotive, and aerospace applications due to their high energy density. They are one of the most popular type of battery . since with the best energy-to-weight ratios, no memory effect, etc.

这里可以自定义设置

Product Characteristics

Place of Origin	Guangdong, China
Brand Name	Vglory or OEM
Model Number	BP60V20AH
Capacity	60v20ah
Battery type	Solar power battery solar power battery , e-motorcycle, e-tricycle/rickshaw, e-golf cart
Material	Lifepo4 cell
Warranty	2 Year
Charge Current	0.2C
Discharge Current	0.5C
Charge Cut-off Voltage	71.4v
Discharge Cut-off Voltage	51v

Product Details

We have professional cell engineer and mechanical engineer who can design the ideal battery pack according our customer’s

mechanical and electric requirement balanced with suitable cost structure

这里可以自定义设置

Our Lithium Battery Features

Environment-friendly

Accredited with CE,Pollution-free, environment friendly , Non-toxic, non-contaminating

Compacted size and super light weight

About 1/2 the volume and 1/3 the weight of the lead-acid battery, small size and high power performance , with the best power-to-weight radio.

Wide temperature range

Excellent widely temperature range performance from :-20°C~+60°C

High energy capacity density

Energy density per volume is high

Long life-cycles

Rechargeable be circularly used , more than 2000 charge /discharge cycle , 8times of Lead-acid battery

Low internal resistance

which ensure the best performance of lithium battery pack Economical : the average price per year is less than the lead-acid battery.

Good power performance

Capacity, resistance, Voltage, platform time consistency is good , also strong current charge and discharge capability

No memory effect

always ready for charge and discharge , no need to charge after a full discharge

PCM & BMS Protection

Protection - Dual IC chips, anti-short circuit, anti-over charger, anti-over current, anti-overload etc

Customized accepted

We could design all battery packs per your’ requirements and provide OEM service

Deep cycle & maintenance free

Only charge every month if store the battery

Very low internal resistance & very low self-discharge rate

Component Advantage

High quality Standard of Vglory Battery

Battery cell

Our engineer will test full performance including long life cycle status , make sure A grade battery cells , 100% quality assurance.

Charger

Designed with metal casing built-in cooling system , which ensure the charge safety and prolong lifespan of battery , Bluetooth function : customized function per request , viewing full details of battery status via APP any time

Intelligent BMS system

With professional design and strictly quality control system according to ISO 9001.2018 . the BMS has a strong and reliable heart from SEIKO/RIOCH/TI , all been take 100% quality check before production

LED indicator

Show battery capacity status clearly with displaying

Battery Pack design

All battery pack is been designed basing the best mechanical and electric requirement

Wire & Plug

We will tailored the qualified wire & plug basing different battery pack

Product Application

Widely used in fields such as: E-mobility: (e-bike , e-scooter, e-skateboard, e-tourist car , e-motorcycle,

e-tricycle /rickshaw , e-wheelchair, e-golf cart, e-forklift, e-tourist vehicle, RV/ caravan, marine,etc.),

UPS: uninterruptible power supply/ UPS/ Backup Power ), UPS emergency lights

Telecom Base, telecom base station

Portable Power Station

Marine: boat, Yacht, Marine battery
