Self Balance 36 Volt Lithium Bike Battery 20Ah Ebike Battery Pack Factory Price

Self Balance 36 Volt Lithium Bike Battery 20Ah Ebike Battery Pack Factory Price

Add success, do you want to check your shopping cart?

Quick Details
Brand Name:
Vglory Or OEM
Model Number:
Place of Origin:
Battery type:
Lithium Bike Battery
Product name:
lithium battery manufacturers
Li-Ion cell
1 Year
Charge Current:
Discharge Current:
Charging Temp:
Discharging Temp:
Storage Temp:
-5℃~35℃ ≤75% RH

Packaging & Delivery

Selling Units:
Single item
Single package size:
33X26X25 cm
Single gross weight:
8.000 kg
Lead Time :
Quantity(Pieces) 1 - 1 2 - 100 >100
Est. Time(days) 15 25 To be negotiated

Self Balance 36 Volt Lithium Bike Battery 20Ah Ebike Battery Pack Factory Price


The li-ion electric bike battery is more safe and reliable than the lead acid one. It does not explode or burn when bump, heavy stress, needle pricking, short circuit, overcharge and overheat. Environment-friendly: Accredited with CE, without any hazardous and noxious substances , with most long cycle life,Small in volume with light weight.

A key advantage of using Li-ion chemistry is the high open circuit voltage that can be obtained in comparison to aqueous batt

eries (such as lead acid, nickel metal hydride and nickel cadmium).


It is Perfect apply used in fields such as E-mobility (e-bike, e-scooter, e-skateboard, e-motorcycle, etc ...




Self Balance 36 Volt Lithium Bike Battery 20Ah Ebike Battery Pack Factory Price

Nominal Voltage36V
Nominal Capacity20Ah
WeightApprox 4.5KG
Standard Charge MethodCC/CV
Cut-Off overcharge Voltage42v
Cut-Off Discharge Voltage30v
Composed Type10S6P
Cell18650 3000mah 3.7V 60pcs
Standard DischargeConstant Current 0.2C/End Voltage 30V
Standard Charge Current0.2C
Max Charge Current1C
Cycle Life800 times
Application forElectric Bike Battery
Charge Temp0~45℃ 60±25%R.H.
Discharge Temp


Storage temperature-20~35°C,45-75%RH
Charging Time (Std.)4~5hours
Charging Time (Max.)2~3hours
Protection functionOver-Current Protection,Over-Discharge Protection, Over-Charge Protection,Short-Circuit Protection, Balance



Advantage Features of Lithium Ion Lithium Ebike Battery :


1 . High energy capacity density and Stable Discharge Voltage

2 . Wide temperature range: Stable good performance under different temperature environment condition

3 . Consistency: Low internal resistance ,Capacity, Voltage, platform time consistency is good

4 . Environment-friendly: Clean and green energy ,  not include any hazardous and noxious substances.
5 . Compact size With light weight:  the best power-to-weight radio : 1/3 of lead acid battery weight

6 . Good Voltage performance: Outstanding Discharge properties and Storage Capacity

7 . low self-discharge rate, less than3% monthly
8 . Long cycle life: over 500 cycles .
9. No memory effect: Be charged & discharged at anytime as No memory effect, economically and conveniently .



Production precedures under skillful performance :
Material Mixing :
Our raw material take the way of vacuum high-speed mixing to achieve the effect of viscosity stability through disperse and symmetrical stirring of slurry materials .
Coating : The density of the coating can be controlled within 3mg . the thickness of the roller can be controlled within 3mu.
Capacity Separating :
Multi-function intelligent Sub-cabinet can automatically alarm the unqualified products to ensure that the product pass rate can reach 100%
Battery cells sorting :
Using Imported control IC intelligent sorting machine , filter the voltage , Automatic sorting ,ensure Cell's consistency , discharge more uniform , to maintain a stronger endurance and life .
Aging Testing :

  • Speed up the battery internal electrolyte activity .
  • Improve the battery’s cycle life and battery stability
  • Improve the consistency of the battery pack .

Spraying the Code :
The processing of assembly and spraying the code of batteries can record the capacity , voltage , power , production time , and production batch of each cell for easier trace in the future .

E-Mobility : electric bike, electric scooter, e-skateboard, e-motorcycle, e-tricycle/rickshaw, e-golf cart, e-forklift, e-tourist vehicle , electric vehicle , cleanness car, E-tour car ,electric bus, electric wheelchairs, ETC .

Battery Precaution and Safety Instructions :
1 . Do not throw battery into water ,keep it away from water, salt, acidic , etc.
2 . Do not throw the battery into fire or heat the battery;
3 . Do not reverse the polarity of the battery pack for any reason.
4 . Forbid to connect the positive and negative terminal directly.
5 . Shocks, high temperature, or contacts of sharp edge components should not be allowed in battery pack assembling process .
6 . Do not directly solder the battery and pierce the battery with a nail or other sharp objects
7 . Remove the battery from the device and separated, avoid metal contact with the battery, causing short-circuit or damage to the phenomenon.
8 . Do not transport or store the battery together with metal objects such as hairpins, necklaces, etc.
9.  If long-term not in use , use battery charger to charge half full state ,
10 . Should be stored in clean, dry and ventilating place .
11 . Battery end of life should be immediately removed from the equipment, Please properly handle security of spent batteries ,
12 . Please use 0.5C current to charge up 60% capacity after the battery placed 3 months , storage in cool conditions without direct sun light on the packs or box
13 . In use or during storage , if found the battery has been high fever, leakage, odor, distortion and other anomalies, please immediately stop using and stay away from the battery .


We can customise the Battery pack per customers' requirements !

The product can easily and conveniently be recharged with a simple battery charger, which is very convenient for people. This product is ideal for power tools and electric vehicles. The product is most commonly used for energy storage for many electronics because it has higher cell voltage and lower cost. This product is ideal for power tools and electric vehicles.
