High Conversion Folding Solar Panels 3x50w Best Portable Solar Panels For RV

这里可以自定义设置
High Conversion Folding Solar Panels 3x50w Best Portable Solar Panels For RV
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Vglory or OEM
Model Number:
VG-FM-050*3
Material:
Monocrystalline Silicon
Max. Power:
150w
Size:
505*690*90
Product name:
solar panel kits
Solar cell:
Mono 156*156 Cell
Peak power(WP):
150W
Warranty:
25 Years Output Power Guarantee
Frame:
Anodized Aluminium Alloy
Tempered Glass:
3.2mm Low-iron & Anti-reflective coating
Backsheet:
Double-sided fluorine TPT
EVA:
anti-aging resistance
Junction Box:
General international standard IP65
Keyword:
portable solar
Supply Ability
Supply Ability:
5000 Piece/Pieces per Month

High Conversion Folding Solar Panels 3x50w Best Portable Solar Panels For RV



This excellent waterproof 150W folding portable solar panel is designed to provide power for charging 12V batteries freely in vehicles and boats ( motorhome , camper, narrow boat,caravan, yacht etc) or any other systems with a 12V battery or battery bank storage .



Solar power is renewable .There are many different technologies that take advantage of solar energy that are quite advanced, There are many technologies, including solar panels, that use the energy such as solar chemicals and heating cells, which absorb the energy to provide heat or electricity . Solar energy is simply energy from the sun. This is a huge leap from fossil fuels energy , which have a limited amount . Solar energy is not as readily as accessible and requires more advanced technologies to derive the same amount of energy as other world energy sources . A solar electric system powers generate power for you inexhaustible  . so you use considerably less electricity from the public city utility. the countries and states more and more emphasize in the global worsening environment problem .



Solar panel kits are making a good start try going solar .  it is great tools helping you become more power energy efficient and “off the grid”. Solar energy it is total green , no CO2 emission , no any Harmful substances emission , no air polluted . so start make contribution to our worsening environmnet in world today and going solar now .



  1. Low voltage-temperature coefficient allows higher power output at high-temperature condition
  2. High efficient, high reliable solar cells ensure our product output stability
  3. Portable design Superior Folding size  portability
  4. Perfect for outdoor operation and outdoor activities also good for marine applications ,
  5. Advanced fully automated solar charge controller with enhanced protection functions
  6. Adjustable aluminium stand, handle and latches
  7. Plug and Play, simply and Practical,use .



Cell size(mm):156*51.5
Power tolerance:±3%
Peak power(WP):150w
Voltage at Pmax(Vmp):18
Current at Pmax(Imp):8.33
Open circuit voltage(Voc):21.6
Short circuit current(Isc):9
Max system voltage(VDC):1000V(IEC)
Operating Temperature:-40℃ to + 85℃
Conversion Efficiency:17.26%
Temperature Coefficient of Pmax:-0.48%/℃
Temperature Coefficient of voc:-0.34%/℃
Temperature Coefficient of ISC:0.015%/℃
Nominal Operating Cell Temperature:45+/-2℃
Data under standard testing conditions(STC)1000W/M²; 1.5AM
Type of Connector:Battery clip
Dimension(mm):505*690*90





1). High Conversion Efficiency Solar Panels’ Cells are laminated with TPT and EVA and encapsulated with Low-iron tempered glass ensuring longer life and maximum performance
2). Anti-aging EVA, high resistant TPT to laminate and stronger anodized aluminum alloy frame
3). Strong aluminum frame withstand heavier snow load and higher wind-pressure by passing mechanical load test 2400Pa ~5400Pa ,
4). Aesthetic appearance and rugged design to withstand high wind pressure, hail and snow load ;
5). Ip65 Junction box with Built-in diodes prevents reverse charging and keep excellent protection ;
6). Rigorous quality control meet the highest international standards and classification of modules
7). Advanced photovoltaic technologies is resistant to atmospheric exposure and effects of delaminating;
8). The exterior design and electrical performance of each every module are fully tested to guarantee superior quality of 25years lifespan .



1). Enjoy our Excellent quality, competitive price, prompt delivery and on-time service
2). High efficiency, high safety, High stability ,high reliability
3). 2.Customized design is available, OEM is welcomed
4). Optimized Packaging to protect product during loading and delivery .
5). Strong productive ability and quick delivery .



Vglory energy is an international PV supplier manufacturer in China since 2006 with strong R&D team etc. mainly producing solar panels range from 1w to 320w , annual 300MW solar panel and solar products production capacity. 80% of our products are export to more than 60 countries in the world. With advanced materials and imported equipments , with 200 skilled workers which pass our training before working ,our modules are designed and manufactured in superior quality ensuring excellent electrical performance and the long span of 25 years for the solar panels.













Vglory has constructed a relatively complete Lithium Batteries process line to ensure the quality. This product offers significant advantages such as charge efficiency. Vglory Group Energy CO., Ltd's technical security and R&D capabilities are first class in the industry. This product offers significant advantages such as charge efficiency.
