Model: BLP24V200Ah
MOQ: 5pcs
Payment: T/T , Western Union , Paypal ,
Delivery time: 10days ~ 15days
Start Port: Shenzhen
Certification: CE , ROHS , MSDS , UN38.3
Specification of lithium battery 24v 200ah | ||
No. | Items | Specs |
1 | Model | High Power Output lithium battery 24v 200ah Rechargeable Batteries |
2 | Chemistry | Lifepo4 battery cell |
3 | Nominal Voltage | 24V |
4 | Rated Capacity | 200Ah |
5 | Battery Cell | 3.2V lifepo4 battery cell |
6 | Battery size | 380*380*290mm or Custom |
7 | Battery Weight | 48 kgs |
8 | Standard Charge Current | ≤ 20A~40A or custom |
9 | Max Constant Discharge Current | ≤ 100A or custom |
10 | Continuous Discharge Current | ≤ 50A or custom |
11 | Standard Discharge | Constant Current 0.2C/End Voltage 2.65V cell |
12 | Fully charged Voltage | 29.6V( 3.7V per cell) |
13 | Discharge cut off voltage | 20v |
15 | Cycle Life | >2000 times (80% of initial capacity at 0.2C rate) |
16 | Way of Charge | CC/CV(Constant Current / Constant Voltage) |
17 | Charge Temperature | 0~45°C 60±25%R.H. |
18 | Discharge Temperature | -20~55°C 60±25%R.H. |
19 | Storage temperature | -0~35°C 45-75% R.H. |
20 | Protection Function | Over-Current Protection,Over-Discharge Protection, Over-Charge Protection,Short-Circuit Protection, Teperature, Balance |
Product Description
Vglory battery manufacturer offers high level safety battery through assembled with high quality A grade cell. which are good replacement of lead-acid batteries and good compatible in all respects with those of lead battery . the charging system can be kept the same and no additional accessories are required to perform the replacement.
Lithium ion batteries are common in consumer electronics. They are one of the most popular types of battery for portable power, with one of the best energy-to-weight ratios, no memory effect, and a lower loss of charge when in storage. In addition to uses for consumer electronics, lithium-ion batteries are growing in popularity for defense, automotive, and aerospace applications due to their high energy density. Li-ion batteries are lighter than other equivalent secondary batteries-often much lighter. The energy is stored in these batteries through the movement of lithium ions.
Product Characteristics
Place of Origin | Guangdong, China |
Brand Name | Vglory or OEM |
Model Number | BLP24V200AH |
Capacity | 24v200ah |
Battery type | solar power battery |
Product name | best battery for solar system |
Material | Li-Ion cell |
Warranty | 2 Year |
Charge Current | 0.2C |
Discharge Current | 0.5C |
Charge Cut-off Voltage | 29.6v |
Discharge Cut-off Voltage | 20.0v |
Battery cells capacity sorting
Automatic cell grading sorting ensure the precision of cell balance as ensure the best capacity and quality of battery pack
Battery cells IR & multi testing
Undertaking internal resistance testing ensure the best consistency of best quality battery pack , as ensure best power performance and prolong lifespan of battery pack
Automatic Welding machine
Which can avoid insufficient welding as ensure the high quality battery pack assembling . which can improve production efficiency mostly
Comprehensive Testing
Using automatic test equipment , comprehensive test of large batteries , cycles , IR, consistency , accurate data , perfect curve , ensure 100% qualified
Automatic sticker machine
The processing of assembly the barcode of batteries can record the capacity , voltage , power , production time , and production batch for easier trace in the future
Package design
Our professional engineer will design the strong package for lithium battery which ensure the safety transportation of lithium battery , which would avoid severe vibrating, impacting , extrusion , and direct light and rain
Advantage of our company
1: Quick response: quick reply within 24 hours
3: Good quality: We will arrange production of your order as soon as possible , Provide with best quality lithium battery pack , superior quality and best cost-performance ratio ;
4: Fast delivery: once order confirmed , we will make production arrangement and get ready asap ! For sample order, we will ship in around 7 days, for bulk order , we will arrange shipment approx. 15 days .
5: QC checking: 100% quality test before ship out .
6: Professional Logistic: We have professional logistic team which are rich experiences in sourcing the best channel & handling shipments for clients , arrange shipment by air or by sea per requirement .
7: Tracking Shipments: We will track the shipping status timely ensure our buyers can receive goods in time and safely .
8: The most important is with factory lower price , super high quality lithium battery pack !
9: 3 years warranty which ensure provide client with the best quality !
