Best Lithium solar battery 24v 200ah lifepo4 rv battery for sale

这里可以自定义设置
Best Lithium solar battery 24v 200ah lifepo4 rv battery for sale
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Model: BLP24V200Ah

MOQ: 5pcs

Payment: T/T , Western Union , Paypal ,

Delivery time: 10days ~ 15days

Start Port: Shenzhen

Certification: CE , ROHS , MSDS , UN38.3


Add success, do you want to check your shopping cart?

暂无分享
该产品后台详情无内容

Product Parameters

That guarantee us to supply most competitive cells , battery pack and BMS solutions with advanced lithium technology .

Specification of lithium battery 24v 200ah

No.

Items

Specs

1

Model

High Power Output lithium battery 24v 200ah Rechargeable Batteries

2

Chemistry

Lifepo4 battery cell

3

Nominal Voltage

24V

4

Rated Capacity

200Ah

5

Battery Cell

3.2V lifepo4 battery cell

6

Battery size

380*380*290mm or Custom

7

Battery Weight

48 kgs

8

Standard Charge Current

≤ 20A~40A or custom

9

Max Constant Discharge Current

≤ 100A or custom

10

Continuous Discharge Current

≤ 50A or custom

11

Standard Discharge

Constant Current 0.2C/End Voltage 2.65V cell

12

Fully charged Voltage

29.6V( 3.7V per cell)

13

Discharge cut off voltage

20v

15

Cycle Life

>2000 times (80% of initial capacity at 0.2C rate)

16

Way of Charge

CC/CV(Constant Current / Constant Voltage)

17

Charge Temperature

0~45°C 60±25%R.H.

18

Discharge Temperature

-20~55°C 60±25%R.H.

19

Storage temperature

-0~35°C 45-75% R.H.

20

Protection Function

Over-Current Protection,Over-Discharge Protection, Over-Charge Protection,Short-Circuit Protection, Teperature, Balance

Product Description

Vglory battery manufacturer offers high level safety battery through assembled with high quality A grade cell. which are good replacement of lead-acid batteries  and good compatible in all respects with those of lead battery . the charging system can be kept the same and no additional accessories are required to perform the replacement.


 Lithium ion batteries are common in consumer electronics. They are one of the most popular types of battery for portable power, with one of the best energy-to-weight ratios, no memory effect, and a lower loss of charge when in storage. In addition to uses for consumer electronics, lithium-ion batteries are growing in popularity for defense, automotive, and aerospace applications due to their high energy density. Li-ion batteries are lighter than other equivalent secondary batteries-often much lighter. The energy is stored in these batteries through the movement of lithium ions.

这里可以自定义设置

Product Characteristics

Place of Origin

 Guangdong, China

Brand Name

 Vglory or OEM

Model Number

 BLP24V200AH

Capacity

 24v200ah

Battery type

 solar power battery

Product name

 best battery for solar system

Material

 Li-Ion cell

Warranty

 2 Year

Charge Current

 0.2C

Discharge Current

 0.5C

Charge Cut-off Voltage

 29.6v

Discharge Cut-off Voltage

 20.0v

Product Details

We have professional cell engineer and mechanical engineer who can design the ideal battery pack according our customer’s

mechanical and electric requirement balanced with suitable cost structure

这里可以自定义设置

Our Strict quality testing for battery pack processing

Battery cells capacity sorting

Automatic cell grading sorting ensure the precision of cell balance as ensure the best capacity and quality of battery pack

Battery cells IR & multi testing

Undertaking internal resistance testing ensure the best consistency of best quality battery pack , as ensure best power performance and prolong lifespan of battery pack

Automatic Welding machine

Which can avoid insufficient welding as ensure the high quality battery pack assembling . which can improve production efficiency mostly

Comprehensive Testing

Using automatic test equipment , comprehensive test of large batteries , cycles , IR, consistency , accurate data , perfect curve , ensure 100% qualified

Automatic sticker machine

The processing of assembly the barcode of batteries can record the capacity , voltage , power , production time , and production batch for easier trace in the future

Package design

Our professional engineer will design the strong package for lithium battery which ensure the safety transportation of lithium battery , which would avoid severe vibrating, impacting , extrusion , and direct light and rain

Component Advantage

High quality Standard of Vglory Battery

Advantage of our company

1: Quick response: quick reply within 24 hours
3: Good quality: We will arrange production of your order as soon as possible , Provide with best quality lithium battery pack , superior quality and best cost-performance ratio ;
4: Fast delivery: once order confirmed , we will make production arrangement and get ready asap ! For sample order, we will ship in around 7 days, for bulk order , we will arrange shipment approx. 15 days .
5: QC checking: 100% quality test before ship out .
6: Professional Logistic: We have professional logistic team which are rich experiences in sourcing the best channel & handling shipments for clients , arrange shipment by air or by sea per requirement .
7: Tracking Shipments:  We will track the shipping status timely ensure our buyers can receive goods in time and safely .
8: The most important is with factory lower price , super high quality lithium battery pack !
9: 3 years warranty which ensure provide client with the best quality !

Product Application

Energy Storage Systems: (solar energy power system , Solar LED light, Solar storage battery , energy storage system,

camping light , solar emergency light,  City Grid (On / Off) , Industrial , Community and Home

这里可以自定义设置
